WSPR Beacon
by IgrikXD
Built by IgrikXD, WSPR Beacon is an open hardware wireless board released with its design files intact. The author describes it as: “A compact hardware device for transmitting WSPR messages based on the SI5351 clock generator, using GPS for transmission timing synchronization and automatic QTH locator calculation.”
125 people have starred it and 12 have forked it, with the last commit 2 months ago.
What’s in the repository
- Schematic and board source files published by the author
- A project site with further documentation
- Full revision history, so you can see how the board changed between versions
Licence and reuse
Released under GPL-3.0, a copyleft license. You are free to fork and modify the design, but anything you distribute that is derived from it has to be published under the same terms — worth checking before it goes into a closed product.
