DSBClone is a community-built retro computing board. Rolel publishes the full project on GitHub for anyone to study or build. The project summarises itself as “A replacement PCB for the SEGA Digital Sound Boardscused on several SEGA arcade games.”
The repository has collected 13 stars and been forked 6 times, with the last commit 10 months ago.
What’s in the repository
- Schematic and board source files published by the author
- Full revision history, so you can see how the board changed between versions
Licence and reuse
Released under GPL-3.0, a copyleft license. You are free to fork and modify the design, but anything you distribute that is derived from it has to be published under the same terms — worth checking before it goes into a closed product.
