Porcupine
by anarion80
Porcupine is a input device published by anarion80, with public design files on GitHub. Check the repository terms before reuse. The author describes it as: “Porcupine is an autogenerated, ergonomic, split, 36-42 key, wired/wireless, columnar-staggered keyboard.”
56 people have starred it and 10 have forked it, with the last commit 2 years ago.
What’s in the repository
- Schematic and board source files published by the author
- Full revision history, so you can see how the board changed between versions
Licence and reuse
The project ships its own license terms rather than a standard SPDX license. Open the license file in the repository and read it before you reuse the files — custom hardware licenses often restrict commercial manufacture.
Opening it in ProtoFlow
The repository does not clearly state which EDA tool produced the files — check the repository contents before planning an import.
- 01 Select “Edit in ProtoFlow” for opening options. Download the source and open supported KiCad files in the app. Other EDA formats may need conversion.
- 02 Work in the imported local copy: rename nets, swap parts against live distributor stock, re-route, or strip it back to the sub-circuit you actually need.
- 03 Keep the original licence and credit anarion80 if you publish or sell what you build from it.
This page indexes a public repository. The design, the files and the copyright belong to anarion80; ProtoFlow does not host, mirror or verify them. Details are read from GitHub and refreshed periodically — check the repository for the current state of the project.
