paw3395 Pcb
by badjeff
paw3395 Pcb is an open source input device published by badjeff, with its KiCad design files available on GitHub. The project summarises itself as “An open source breakout board for PixArt PAW3395DM-T6QU / PAW3950DM-T5QU low power optical mouse sensor.”
The repository has collected 37 stars and been forked 8 times, with the last commit 3 months ago.
What’s in the repository
- KiCad schematic and PCB layout source files
- Full revision history, so you can see how the board changed between versions
Licence and reuse
Released under CERN-OHL-P-2.0. Read the license file in the repository before reusing the design commercially; the terms are not one of the common permissive or copyleft templates.
Opening it in ProtoFlow
Select Edit in ProtoFlow for the available opening options. Download the source and open supported KiCad schematic or board files in the desktop app; check the project version and external libraries.
- 01 Select “Edit in ProtoFlow” for opening options. Download the source and open supported KiCad files in the app. Other EDA formats may need conversion.
- 02 Work in the imported local copy: rename nets, swap parts against live distributor stock, re-route, or strip it back to the sub-circuit you actually need.
- 03 Keep the original licence and credit badjeff if you publish or sell what you build from it.
