BenjaminSoelberg maintains Elektronika 1, an open hardware display and LED board whose KiCad source files are public on GitHub. The author describes it as: “A replacement module for the USSR vintage LED watch Elektronika-1 anno 1978.”
29 people have starred it and 1 have forked it, with the last commit 5 years ago.
What’s in the repository
- KiCad schematic and PCB layout source files
- Full revision history, so you can see how the board changed between versions
Licence and reuse
Released under GPL-3.0, a copyleft license. You are free to fork and modify the design, but anything you distribute that is derived from it has to be published under the same terms — worth checking before it goes into a closed product.
