rc2014 ym2149
by electrified
rc2014 ym2149 is a retro computing board published by electrified, with public KiCad design files on GitHub. Check the repository terms before reuse. In the maintainer's words: “KiCad schematics and gerbers for a YM sound card for the RC2014. See it in action here: https://www.youtube.com/watch?v=-iLwi9FagFE.”
It has 78 stars and 17 forks on GitHub, with the last commit 2 months ago.
