GB Dumper
by wodowiesel
Built by wodowiesel, GB Dumper is an open hardware interface board released with its design files intact. The author describes it as: “GB-Dumper is a PCB project for Gameboy cartridge dumps and backups via Arduino Nano on spi-bus & USB.”
14 people have starred it and 1 have forked it, and the files were touched within the last month.
What’s in the repository
- Schematic and board source files published by the author
- A project site with further documentation
- Full revision history, so you can see how the board changed between versions
Licence and reuse
Released under CC0-1.0, one of the permissive licenses. You can fork the design, change it, manufacture it and sell the result, provided you keep the original copyright and license notice with the files.
