BeanCounter
by NPoole
BeanCounter is an open source sensor board published by NPoole, with its EAGLE design files available on GitHub. In the maintainer's words: “SMT parts counter that fits in your pocket.”
It has 223 stars and 72 forks on GitHub, with the last commit 8 months ago.
What’s in the repository
- EAGLE schematic (.sch) and board (.brd) source files
- A project site with further documentation
- Full revision history, so you can see how the board changed between versions
Licence and reuse
Released under CC-BY-SA-4.0, a copyleft license. You are free to fork and modify the design, but anything you distribute that is derived from it has to be published under the same terms — worth checking before it goes into a closed product.
Opening it in ProtoFlow
The design was drawn in EAGLE. EAGLE schematic and board files convert into KiCad format, which is the path to take if you want to carry this design into ProtoFlow.
- 01 Select “Edit in ProtoFlow” for opening options. Download the source and open supported KiCad files in the app. Other EDA formats may need conversion.
- 02 Work in the imported local copy: rename nets, swap parts against live distributor stock, re-route, or strip it back to the sub-circuit you actually need.
- 03 Keep the original licence and credit NPoole if you publish or sell what you build from it.
This page indexes a public repository. The design, the files and the copyright belong to NPoole; ProtoFlow does not host, mirror or verify them. Details are read from GitHub and refreshed periodically — check the repository for the current state of the project.
