Arduino Reflow Oven Controller is a community-built microcontroller board. kalanda publishes the full EAGLE project on GitHub for anyone to study or build. In the maintainer's words: “Reflow Oven Controller for soldering of SMD components based on Arduino.”
It has 17 stars and 2 forks on GitHub, with the last commit 7 years ago.
What’s in the repository
- EAGLE schematic (.sch) and board (.brd) source files
- Full revision history, so you can see how the board changed between versions
Licence and reuse
Released under MIT, one of the permissive licenses. You can fork the design, change it, manufacture it and sell the result, provided you keep the original copyright and license notice with the files.
