Built by chilly23, Ant Board rev1 is an open hardware microcontroller board released with its EasyEDA design files intact. In the maintainer's words: “Compact USB-C development board concept built around the Microchip ATSAMD11D14A, developed by UI.”
It has 14 stars and 0 forks on GitHub, with the last commit 2 months ago.
What’s in the repository
- EasyEDA project source files
- Full revision history, so you can see how the board changed between versions
Licence and reuse
Released under CERN-OHL-S-2.0. Read the license file in the repository before reusing the design commercially; the terms are not one of the common permissive or copyleft templates.
Opening it in ProtoFlow
The design was drawn in EasyEDA. EasyEDA can export to KiCad format, which is the route into ProtoFlow or any KiCad-based workflow.
- 01 Select “Edit in ProtoFlow” for opening options. Download the source and open supported KiCad files in the app. Other EDA formats may need conversion.
- 02 Work in the imported local copy: rename nets, swap parts against live distributor stock, re-route, or strip it back to the sub-circuit you actually need.
- 03 Keep the original licence and credit chilly23 if you publish or sell what you build from it.
